Medial ve bikondiler tibia plato kırıkları

Özet

Medial kondil veya bikondiler plato kırıkları yüksek ya da düşük enerjili travmayla oluşabilir; yüksek enerjili yaralanmalarda daha karmaşık kırık örüntüsü beklenir. BT tabanlı kırık haritalaması, plato kırık çizgilerinin aksiyel, koronal ve sagittal düzlemlerde dağılımını değerlendirmeye olanak verir. Metafiz-diafiz devamlılığının kopması, bikondiler kırığı metafiz-diafiz ayrışması bulunan bir patern olarak tanımlar. Bikondiler kırıklarda posteromedial fragman farklı serilerde %30 ile yaklaşık %65 arasında bildirilmiştir; bu ve diğer posterior fragmanların değerlendirilmesi tedavi stratejisini etkileyebilir.

Faz ve pencere

Kontrastsız tanısal

Koronal, aksiyel ve sagittal BT değerlendirmesi kırık çizgilerinin farklı düzlemlerdeki dağılımını gösterir.

Önerilen pencereler: Kemik (G 1800 / M 400), Yumuşak doku (G 400 / M 40).

BT bulguları

• Medial kondil kırığı — medial eklem yüzü ve kondil içinde vertikal veya oblik ayrışma çizgisi izlenir.
• Bikondiler tutulum — medial ve lateral plato kondillerini birlikte içeren kırık örüntüsüdür.
• Posteromedial fragman — koronal hatta sınırlı görünse de aksiyel kesitlerde arka korteks boyunca ayrı eklem parçası oluşturabilir.
• Posterior shear kırığı — posterior kolonda eklem çökmesi ve posterior duvar kırığı ile tanımlanır.
• Metafiz-diafiz ayrışması — eklem taşıyan proksimal fragman ile distal tibia şaftı arasında kortikal devamlılık kaybolur.
• İnterkondiler eminens kırığı — tibial eminens, tip C plato kırıklarında sıklıkla tutulabilir.
• Fibula başı avulsiyonu — lateral bağ kompleksi yapışma yerindeki küçük kemik parçası eşlik eden yaralanmayı gösterir.
• Lipohemartroz — eklem içi yağ ve kan katmanlanması eşlik eden intraartiküler kırığı doğrular.

Ölçütler ve sınıflamalar

Schatzker

Tip IV medial plato kondil kırığıdır; tip V bikondiler kırıkta eklem taşıyan metafiz-diafiz bağlantısı sürer; tip VI bikondiler kırıkta metafiz-diafiz ayrışması vardır.

AO/OTA 41

B tipi parsiyel artiküler, C tipi tam artiküler proksimal tibia kırığıdır; C grubunda eklem yüzü ile diafiz arasında devamlılık kaybolur.

Üç kolon sınıflaması

Proksimal tibia üç kolon (lateral, medial, posterior) olarak modellenir; her kolonda bağımsız eklem fragmanı varsa üç-kolon kırığı kabul edilir ve tedavi yaklaşımı buna göre planlanır.

Normalde

Normal proksimal tibia eklem yüzünde medial ve lateral plato korteksleri kesintisiz, tibial eminens ortada ve metafiz korteksi diafize devamlıdır. Aynı koronal kesitlerde iki kondilin yüzey bütünlüğünü, aksiyel kesitlerde posterior duvarı ve sagittalde eklem taşıyan fragmanın şaftla bağlantısını kontrol edin.

Ayırıcı tanı

İzole lateral split-depresyon

kırık yalnız lateral kondili tutar; medial plato ve şaft bağlantısı sağlamdır.

Posterior shear kırığı

posterior kolonda eklem çökmesi ve posterior duvar kırığıyla tanımlanır; bikondiler kırıkta medial ve lateral kondiller birlikte tutulur.

Segond avulsiyonu

anterolateral plato altındaki küçük kortikal kopmadır; medial kondil veya iki kondil boyunca uzanan kırık değildir.

Tuzaklar

• Tek AP grafi kırık fragmanlarını tam olarak tanımlamayabilir; BT, kırık örüntüsünü daha ayrıntılı değerlendirmeye olanak verir.
• Eklem taşıyan blok ile distal şaft ilişkisini yalnız eklem seviyesinde değerlendirmeyin; metafiz-diafiz ayrışması koronal ve sagittal planda ortaya çıkabilir.
• Schatzker tipi posterior kolon morfolojisini tam kodlamaz; sınıfı yazdıktan sonra arka fragmanın tarafını ve kortikal duvar durumunu metinde belirtin.

Kendini dene

1. Her iki tibia plato kondili kırılmış, ancak eklem taşıyan metafiz parçası diafizle bağlantısını koruyor. Schatzker tipi hangisidir?

   • Tip V
   • Tip IV
   • Tip VI
   • Tip II
   Cevabı göster

   Tip V. Tip V bikondiler eklem kırığıdır ve metafiz-diafiz devamlılığı korunur. Tip VI'da bu bağlantı ayrılır; tip IV medial kondili, tip II lateral split-depresyonu tanımlar.

2. Bikondiler kırıkta aksiyel BT posterior kortekse ulaşan ayrı posteromedial eklem fragmanını gösteriyor. En doğrudan sınıflama kavramı hangisidir?

   • Posterior kolon tutulumu
   • Saf lateral split
   • Segond avulsiyonu
   • Tibial eminens kırığı
   Cevabı göster

   Posterior kolon tutulumu. Ayrı arka eklem fragmanı ve posterior duvar kopukluğu posterior kolon tutulumunu tanımlar; lateral split kırıklar Schatzker Tip II'yi oluşturur; Segond avulsiyonu anterolateral plato tabanındaki kortikal kopmadır; tibial eminens kırığı ise interkondiler çıkıntı merkezli bir avulsiyondur.

İlgili konular

• Diz lipohemartrozu
• Tibia platosu posterior shear/kolon kırığı
• Segond avulsiyon kırığı

Kaynaklar

Bu sayfadaki 39 cümle ve 2 quiz sorusu aşağıdaki kaynaklardan alıntılarla otomatik olarak karşılaştırıldı; 12 cümle bu karşılaştırmada düzeltildi (2026-10-09).

1. Tibial plateau fractures: three dimensional fracture mapping and morphologic measurementspmc.ncbi.nlm.nih.gov
2. Treatment strategy for tibial plateau fractures: an updatepmc.ncbi.nlm.nih.gov
3. The effect of addition of 2DCT scans and 3DCT scans for the classification of tibial plateau fractures: a systematic reviewpmc.ncbi.nlm.nih.gov
4. Three-column fixation for complex tibial plateau fractures.pubmed.ncbi.nlm.nih.gov
5. Revisiting the Schatzker classification of tibial plateau fractures.pubmed.ncbi.nlm.nih.gov
6. Partial proximal tibia fractures.pubmed.ncbi.nlm.nih.gov
7. Finite element analysis of biomechanical effects of residual varus/valgus malunion after femoral fracture on knee joint.pubmed.ncbi.nlm.nih.gov
8. Tibial Plateau Fracture Characteristics: Computed Tomography Mapping of Lateral, Medial, and Bicondylar Fractures.pubmed.ncbi.nlm.nih.gov
9. Early changes in osteochondral tissues in a rabbit model of post-traumatic osteoarthritis.pubmed.ncbi.nlm.nih.gov
10. Intra-articular tibial plateau fracture characteristics according to the "Ten segment classification".pubmed.ncbi.nlm.nih.gov
11. Comparative Analysis of Mechanism-Associated 3-Dimensional Tibial Plateau Fracture Patterns.pubmed.ncbi.nlm.nih.gov
12. Tibia plateau fracture mapping and its influence on fracture fixation.pubmed.ncbi.nlm.nih.gov
13. Tibial plateau fracture related to unicompartmental knee arthroplasty: Two case reports and literature review.pubmed.ncbi.nlm.nih.gov
14. 3D mapping and classification of tibial plateau fractures.pubmed.ncbi.nlm.nih.gov
15. Classification of tibia plateau fracture according to the "four-column and nine-segment".pubmed.ncbi.nlm.nih.gov
16. Development and Analysis of Mouse Medial Meniscus Posterior Root Tear Model.pubmed.ncbi.nlm.nih.gov
17. Morphologic study of posterior articular depression in Schatzker IV fractures.pubmed.ncbi.nlm.nih.gov
18. A rare traumatic triad: Open bicondylar non-conjoint Hoffa fracture with partial tibial tubercle and medial epicondyle avulsions - A case report and biomechanical analysis.pubmed.ncbi.nlm.nih.gov
19. Three-column Plating for Complex Tibial Plateau Fractures: Multivariate Predictors of Superior Functional Recovery.pubmed.ncbi.nlm.nih.gov
20. Long-term outcomes of dual locking-plate fixation for bicondylar tibial plateau fractures via two mini-incisions: A prospective study.pubmed.ncbi.nlm.nih.gov
21. Glossary of terms for musculoskeletal radiology.pubmed.ncbi.nlm.nih.gov
22. Spontaneous bacteremia and spontaneous bacterial peritonitis share similar prognosis in patients with cirrhosis: a cohort study.pubmed.ncbi.nlm.nih.gov
23. Intramedullary nail fixation for tibial plateau fractures: a systematic review of techniques and outcomes.pubmed.ncbi.nlm.nih.gov
24. The Role of Immediate Arthroplasty in Elderly Tibial Plateau Fractures.pubmed.ncbi.nlm.nih.gov
25. Proximal Tibia Fractures in Osteoporosis.pubmed.ncbi.nlm.nih.gov
26. Anteromedial Tibia Plateau Fracture without Significant Ligamentous Injury Treated Successfully with Open Reduction and Internal Fixation: A Case Report.pubmed.ncbi.nlm.nih.gov
27. Location and risk factors of postoperative deep venous thrombosis in patients with tibial plateau fracture: a retrospective single-center study.pubmed.ncbi.nlm.nih.gov
28. Imaging of pediatric musculoskeletal trauma: Age-specific considerations and challenges.pubmed.ncbi.nlm.nih.gov
29. Sequential Workflow for Integrated Biological Repair in Combined Four-Graft Knee Reconstruction.pubmed.ncbi.nlm.nih.gov
30. Variability of the posteromedial meniscocapsular junction of the knee on MRI: Pitfall to imaging diagnosis of ramp lesions.pubmed.ncbi.nlm.nih.gov
31. Medial Tibial Plateau Fractures and Fracture-Dislocations: A Mechanism-Based Narrative Review of Instability Patterns, Imaging, and Contemporary Management.pubmed.ncbi.nlm.nih.gov
32. Anterior auxiliary limited open incision for Schatzker IV total medial plateau fractures with posterolateral collapse: a retrospective study.pubmed.ncbi.nlm.nih.gov
33. The arrow and the target-description of the "Robin Hood" technique for fixation of tibial spine avulsion fractures: a technical note.pubmed.ncbi.nlm.nih.gov
34. Current concepts in the management of high-energy tibial plateau fractures: a narrative review.pubmed.ncbi.nlm.nih.gov
35. Association between articular surface depression and functional outcomes after ORIF of tibial plateau fractures: a retrospective cohort study.pubmed.ncbi.nlm.nih.gov
36. Novel anatomically contoured locking plate shows improved anatomic conformity vs. a conventional T-shaped plate in anterior popliteus transtibial-tuberosity high tibial osteotomy: a radiologic comparison.pubmed.ncbi.nlm.nih.gov
37. Prospective Five-Point Serial Assessment of Radiological and Functional Outcome Dissociation After Locking Plate Fixation of Proximal Tibial Fractures.pubmed.ncbi.nlm.nih.gov
38. A novel 3DCT-based classification for posterior cruciate ligament tibial avulsion fractures.pubmed.ncbi.nlm.nih.gov
39. Magnetic resonance imaging-based identification of the knee anterolateral ligament: A systematic review with meta-analysis.pubmed.ncbi.nlm.nih.gov
40. A Systematic Approach to the Evaluation of Acute Musculoskeletal Injuries in the Emergency Department.pubmed.ncbi.nlm.nih.gov
41. Single-Stage Repair of Complex Anterolateral Radial and Posterior Root Tears of the Lateral Meniscus, With a Concomitant Multiligament Knee Reconstruction of the Anterior Cruciate Ligament, Medial Collateral Ligament, Posterior Oblique Ligament, and Anterolateral Ligament in a Young Athlete.pubmed.ncbi.nlm.nih.gov
42. A Novel Assessment of Infratubercle Sagittal Proximal Tibial Morphology and Relationship to Full Length Posterior Tibial Slope: Lateral Infratubercle Angle.pubmed.ncbi.nlm.nih.gov
43. Clinical outcomes and complications after proximal tibial detorsional osteotomy for patellar luxation in dogs: A multicenter retrospective study.pubmed.ncbi.nlm.nih.gov
44. Accuracy of Patient-Specific Instruments for Supramalleolar Osteotomies.pubmed.ncbi.nlm.nih.gov
45. Radiographic Osteoarthritis and Patient-Reported Outcomes One Year Following Tibial Plateau Fracture Surgery.pubmed.ncbi.nlm.nih.gov
46. An immunoregenerative approach to mitigate post-traumatic osteoarthritis after intra-articular fracture.pubmed.ncbi.nlm.nih.gov
47. Tibial plateau fractures are associated with ligamentous and meniscal injuries. Preoperative evaluation of magnetic resonance imaging influences surgical treatment.pubmed.ncbi.nlm.nih.gov
48. Column Involvement as a Predictor of Early Functional Outcome and Complications in Proximal Tibia Fractures: A Prospective Study.pubmed.ncbi.nlm.nih.gov
49. Functional Outcomes and Surgical Utility of the Modified Schatzker Four-column Concept in Proximal Tibial Plateau Fractures: A Prospective Observational Study.pubmed.ncbi.nlm.nih.gov
50. Location of lateral tibial plateau fractures relative to the posterolateral complex predicts the need for extension of lateral approaches: A retrospective observational study.pubmed.ncbi.nlm.nih.gov
51. Biomechanical comparison of a novel hockey-stick locking plate with a pes anserinus sparing design for Schatzker IV tibial plateau fractures.pubmed.ncbi.nlm.nih.gov
52. CT measurement of Segond fracture fragment distance to the Gerdy tubercle predicts combined anterolateral ligament and iliotibial band capsulo-osseous layer involvement on MRI.pubmed.ncbi.nlm.nih.gov
53. The iliotibial band revisited: surgical anatomy and imaging-based guidelines for lateral tenodesis in ACL reconstruction.pubmed.ncbi.nlm.nih.gov
54. Current concepts review. Management of proximal tibial fractures.pubmed.ncbi.nlm.nih.gov
55. Different internal fixation methods for Hoffa-like fractures of the tibial plateau: a finite element analysis.pubmed.ncbi.nlm.nih.gov
56. Management of Bone Loss in Revision Total Knee Arthroplasty: An International Consensus Symposium.pubmed.ncbi.nlm.nih.gov
57. Predictive value of a preoperative computed tomography-derived perifracture soft-tissue envelope index for fracture-related infection after open reduction and internal fixation of tibial plateau fractures.pubmed.ncbi.nlm.nih.gov
58. Reconstruction of a Rare Split-Level Bilaminar Patellar Tendon Rupture With Concomitant Multiligament Knee Injury Using Peroneus Longus Autograft: A Case Report.pubmed.ncbi.nlm.nih.gov
59. Patellar Instability: A Narrative Review with an Integrated Treatment Algorithm.pubmed.ncbi.nlm.nih.gov
60. Morphological and postoperative functional comparison of patellar dislocation with or without avulsion fracture of the medial inferior border of the patella.pubmed.ncbi.nlm.nih.gov
61. Role of primary Ilizarov ring fixation for Schatzker Type V and VI bicondylar tibia fracture in tertiary care centre.pubmed.ncbi.nlm.nih.gov
62. Severe medial tibial plateau fractures: feasibility and functional and radiographic results of an extended approach with medial femoral epicondyle osteotomy.pubmed.ncbi.nlm.nih.gov
63. Imaging of the anterior cruciate ligament.pubmed.ncbi.nlm.nih.gov
64. Pediatric emergency medicine point-of-care ultrasound: summary of the evidence.pubmed.ncbi.nlm.nih.gov
65. Avulsion injuries: an update on radiologic findings.pubmed.ncbi.nlm.nih.gov
66. Ultrasound and bone: a pictorial review.pubmed.ncbi.nlm.nih.gov
67. Current clinical, radiological and treatment perspectives of patellofemoral pain syndrome.pubmed.ncbi.nlm.nih.gov
68. Extracapsluar lipohaemarthrosis: A case report and review of literature.pubmed.ncbi.nlm.nih.gov
69. AI detection of knee joint effusion from radiographs: Comparative accuracy of two commercial algorithms.pubmed.ncbi.nlm.nih.gov
70. SPECT-CT: applications in musculoskeletal radiology.pubmed.ncbi.nlm.nih.gov
71. Guidelines on multidisciplinary approaches for the prevention and management of diabetic foot disease (2020 edition).pubmed.ncbi.nlm.nih.gov
72. Long-term safety and effectiveness of the "OptEase" vena cava filter.pubmed.ncbi.nlm.nih.gov
73. Improved Perioperative Outcomes in Robotic-Assisted Revision Total Knee Arthroplasty.pubmed.ncbi.nlm.nih.gov
74. Comparison of short-term clinical results between modified kinematically-aligned and guided motion bicruciate stabilized total knee arthroplasty.pubmed.ncbi.nlm.nih.gov
75. Intra-operative Safety of an Autonomous Robotic System for Total Knee Replacement: A Review of 500 Cases in India.pubmed.ncbi.nlm.nih.gov
76. A study on the association between tibial plateau fractures and intra-articular soft-tissue injuries under valgus injury mechanisms.pubmed.ncbi.nlm.nih.gov
77. Effect of asymmetric anterior and posterior wedge openings on medial and lateral posterior tibial slope in medial open wedge high tibial osteotomy: An in vitro study on sheep tibias.pubmed.ncbi.nlm.nih.gov
78. Osteoarthritis: Epidemiology, Diagnosis, and Treatment.pubmed.ncbi.nlm.nih.gov
79. A Journey into Animal Models of Human Osteomyelitis: A Review.pubmed.ncbi.nlm.nih.gov
80. Risk factors for osteoarthritis in the medial compartment of the stable patellofemoral joint: FTR angle and Wiberg type I patella.pubmed.ncbi.nlm.nih.gov
81. TIBIAL PLATEAU FRACTURES.pubmed.ncbi.nlm.nih.gov
82. Modified Stoppa Approach for ORIF of a Paediatric Transverse Acetabular Fracture: Case Report and Systematic Review of Internal Fixation in Children.pubmed.ncbi.nlm.nih.gov
83. Comparison of the Frosch approach and the supra-fibular head approach in the treatment of posterolateral tibial plateau fractures combined with lateral column fractures.pubmed.ncbi.nlm.nih.gov
84. Fibular head osteotomy: A new technique for better exposure of postero-lateral tibial plateau fracture.pubmed.ncbi.nlm.nih.gov
85. Differential effects of alendronate on chondrocytes, cartilage matrix and subchondral bone structure in surgically induced osteoarthritis in mice.pubmed.ncbi.nlm.nih.gov
86. Surgical Management of Anterior Cruciate Ligament Rupture in Skeletally Immature Adolescents: A Bilateral Transphyseal All-Inside Technique With Patient-Specific Bone Tunnels and Semitendinosus Autograft.pubmed.ncbi.nlm.nih.gov
87. Surgical treatments of bone marrow lesions.pubmed.ncbi.nlm.nih.gov
88. Common Mistakes and Pitfalls in Magnetic Resonance Imaging of the Knee.pubmed.ncbi.nlm.nih.gov
89. Stem cell injections for osteoarthritis of the knee.pubmed.ncbi.nlm.nih.gov
90. Patterns of injury and violence in Yaoundé Cameroon: an analysis of hospital data.pubmed.ncbi.nlm.nih.gov
91. Is Staged Surgery Always Necessary for Schatzker Type IV-VI Tibial Plateau Fractures? A Comparison Study.pubmed.ncbi.nlm.nih.gov
92. Management of increased posterior tibial slope in ACL deficiency: A narrative review and recommendation of the Osteotomy Committee of the German Knee Society.pubmed.ncbi.nlm.nih.gov
93. Association of knee osseous morphometric parameters with degeneration and tear of the discoid lateral meniscus: a cross-sectional quantitative MRI study.pubmed.ncbi.nlm.nih.gov
94. Posterolateral tibia plateau fractures: pros and cons of different surgical approaches.pubmed.ncbi.nlm.nih.gov
95. A case report of the Hoffa fracture and a review of literature.pubmed.ncbi.nlm.nih.gov
96. Fractures Around the Knee-Significant Achievements During the Past 25 Years and Major Questions to Be Solved.pubmed.ncbi.nlm.nih.gov
97. Open Reduction and Internal Fixation Versus Suprapatellar Nailing and Condylar Bolts for the Management of Complex Bicondylar Tibial Plateau Fractures: A Clinical Study.pubmed.ncbi.nlm.nih.gov
98. Deep-Learning System for Automatic Measurement of the Femorotibial Rotational Angle on Lower-Extremity Computed Tomography.pubmed.ncbi.nlm.nih.gov
99. PlaTiF: A pioneering dataset for orthopedic insights in AI-powered diagnosis of tibial plateau fractures.pubmed.ncbi.nlm.nih.gov
100. A Rare Case of Combined Tibial Plateau Fracture with Tibial Tuberosity Avulsion Injury: Case Report.pubmed.ncbi.nlm.nih.gov

Eğitim amaçlıdır; hasta başında tanı ve tedavi kararının yerine geçmez, tıbbi tavsiye değildir. Metinler yapay zekâ desteğiyle yazıldı ve otomatik bir adımda kaynak alıntılarıyla karşılaştırıldı; bu bir tıbbi doğrulama değildir ve içerik uzman radyolog incelemesinden geçmedi. Klinik kararlarda güncel kılavuzları, kurum protokollerini ve radyoloji raporunu esas alın.
